MX20G

Wheeled Excavator

Properties

Cummins B 4.5 L Stage 5 Engine
Heavy-duty construction, built to last
Extensive breakout force, engine power and excavation performance
Large cab with excellent visibility
Highly customisable to your needs
Shortest rear end in its class, from only 1700 mm
Unrivalled stability and lifting power

MXG SERIES

The innovative MXG series represents a leap forward in the world of earthmoving equipment. Its unique combination of compact size and powerful performance makes it ideal for a wide range of applications, from narrow city streets to hectic construction sites. The MX20G, along with its series siblings - MX14G, MX16G, MX17G and MX18G - offer a versatility that ensures a perfect fit for any specific project. Hydrema's focus on the MXG series illustrates our commitment to producing premium machines that can be customised to the individual needs of customers' diverse projects.

MX20G

Hydrema MX20G is the largest model in Hydrema's groundbreaking MXG series of wheeled excavators, distinguished by its efficiency and compact design. This powerhouse is ideally suited for complex tasks in narrow and busy environments. The MX20G is an example of Hydroma's commitment to developing durable and aesthetically pleasing machines that deliver top performance even in tight working conditions. As a key element of the MXG series, the MX20G combines elegant size with strength, making it a versatile player in a wide range of excavation applications.

A FUSION OF POWER AND VERSATILITY

The heart of the MX20G, a flagship of Hydremas MXG range of wheeled excavators, is powered by a powerful Cummins B 4.5 L Stage 5 engine, a testament to the machine's formidable strength and engineering excellence. This engine is equipped with an advanced 16-valve Common-Rail turbo diesel system that delivers an impressive 175 horsepower and 780 Nm of peak torque. The MX20G stands out in the workplace by combining this superior power with outstanding efficiency, even in the most demanding situations. The machine has a large fuel tank and AdBlue system that contributes to economical fuel consumption and compliance with strict environmental standards.

The advanced hydrostatic transmission in the MX20G ensures constant traction on all four wheels. This carefully engineered transmission enables a smooth ride and precise steering, supported by an electronically controlled drive motor and a sophisticated two-speed soft-shift Powershift system. This system allows the driver to switch between manual and automatic gear settings, providing exceptional control and adaptability in varying terrain conditions. The MX20G's design makes it highly adaptable for both on-road and off-road use, ensuring an optimal balance between power and manoeuvrability.

EXCAVATOR

The MX20G features an innovative boom design that can be customised for different tasks thanks to its adjustable lengths of 2.0 m, 2.5 m, and 3.0 m. This flexibility makes the MX20G ideal for a variety of digging projects. In addition, the MX20G is equipped with the option to mount an Engcon tiltrotator, increasing its versatility and making it an optimal choice for a variety of digging tasks. This combination of features makes the MX20G a highly capable and flexible excavator, able to handle a wide range of tasks with ease.

UNDERCARRIAGE

The Hydrema MX20G comes in a single undercarriage setup, designed to fully utilise the machine's performance for lifting and other demanding tasks:

Front dozer bl./rear stabilizers (A3)

undercarriage for MX20G

AXLES

The MX20G wheeled excavator from Hydrema uses high-performance ZF axles, essential for its capacity in demanding conditions. The machine's planetary reduction wheel hubs increase torque and precision, which is ideal for complex digging applications. In addition, the MX20G has built-in brakes on the axles and a front axle with a unique pendulum lock that allows a +/- 8º pendulum angle for increased manoeuvrability.

STEERING

The MX20G from Hydrema utilises advanced steering technology that combines hydraulic steering with emergency steering capability, ensuring constant control in all conditions. This feature is essential for handling unexpected situations where precise manoeuvring is critical. To further enhance the user experience, joystick steering is offered as an option. This joystick system enables smooth and precise control at speeds up to 20 km/h, resulting in a more comfortable driving experience, especially during prolonged use.

HYDRAULIC SYSTEM

Equipped with a sophisticated hydraulic system, the MX20G from Hydrema offers a combination of a dual-circuit Load Sensing system and a dedicated high-pressure pump for slew control, ensuring excellent performance. The system is equipped with electronic power regulation and a Mode Control function that gives the user a choice between precise precision work and a fuel-efficient ECO Mode. The machine has the option of up to three hydraulic circuits, with two as standard, and all are adjustable from the cab.

Oil quantity:

Pump 1: - Working hydraulics - 319 l/min
Pump 2: - Slew hydraulics - 88 l/min

System pressure:

Working hydraulics: - 350 Bar
Slew hydraulics: - 395 Bar
Hydraulic circuit 1, ZV1: - 30-200 L/min
Hydraulic circuit 2, ZV2: - 15-100 l/min
Hydraulic circuit 3, ZV3: - 50-200 l/min

ENGINE

The Hydrema MX20G is powered by an efficient, Cummins B 4.5 L Stage 5-engine, which is a fusion of power and environmental concerns. This engine is equipped with advanced technology including DOC, DPF, and SCR catalyst with AdBlue technology. The engine delivers a powerful performance with up to 175 hp (129 kW) and a maximum torque of 780 Nm. To ensure continuous and efficient operation, the MX20G has a 280 litre fuel tank and a 31.5 litre AdBlue tank, minimising the need for frequent refuelling stops during long work periods.

DRIVING HYDRAULICS & TRANSMISSION

With its hydrostatic propulsion and constant four-wheel drive, the MX20G ensures excellent mobility on all terrains. This model is equipped with an electronically controlled variable drive motor and an integrated brake valve, offering a smooth and controllable driving experience. The MX20G is equipped with a 2-speed soft-shift Powershift transmission, which is suitable for both on-road and off-road conditions and allows the driver to switch between manual and automatic gear settings. This feature provides optimal flexibility and comfort for the driver in different working conditions.

Road gear (km/h): 34
Off-road gear (km/h): 0-9
Creeper gear (km/h): 3.5
traction (kN): 111

Speeds are given for a standard machine with dozer blade and standard tyre fitment. With additional weight such as supports, rotor tilt and heavy attachments or other equipment, the maximum speed may be lower.

ELECTRICAL SYSTEM

The MX20G from Hydrema is equipped with a sophisticated 24V electrical system that ensures reliable performance and long-term durability. The system consists of an efficient 70 Amp. generator and two powerful 12V, 100Ah batteries. Its wiring harness is designed to be both durable and safe, with waterproof connectors for outdoor use, ensuring reliable operation. Maintenance and checks are made easy with easy access to fuses and relays near the cab through a service hatch. An emergency operation function guarantees continued operation in the event of electronic failures, and an automatic circuit breaker offers additional protection. The MX20G is designed to be a stable and efficient partner in any working condition.

AUTOMATIC CIRCUIT BREAKER

The MX20G has an automated circuit breaker offers additional protection. This feature ensures that all electrical systems are automatically switched off when the operator ends use and leaves the cab, saving energy and improving safety. Reactivation of the system is seamless when the driver returns, supported by sensors located in the doors. Equipped with a built-in timer and a controllable shutdown function from the dashboard, this feature makes operation both intuitive and convenient. For additional safety, there is an emergency switch located within easy reach in the cab.

OPERATION

The Hydrema MX20G features user-friendly operation with its efficient control system. Equipped with multifunctional joysticks that include servo functions and push buttons, it ensures precise control. With separate foot pedals for the two-part boom and dozer blade/stabilisers, comfort is increased. Users can adjust hydraulic pressure and flow from the instrument panel, and there are options for further customisation with advanced joystick settings. This makes the MX20G easy and comfortable to operate in all work situations.

KRØJESYSTEM

The Hydrema MX20G's state-of-the-art high-pressure hydrostatic slewing system plays a key role in improving the manoeuvrability of the machine, allowing it to turn 360 degrees. The system increases efficiency by recycling some of the braking energy to the diesel engine. Equipped with a mechanical holding brake for yaw and a soft start function with angle sensors, the MX20G ensures a smooth swing speed of 10.8 rpm and a powerful swing torque of 50 kNm, ideal for precise work.

BRAKES

To ensure maximum safety and control, the MX20G from Hydrema comes with a state-of-the-art braking system. This model includes a dual-circuit braking system with maintenance-free oil immersed brakes on all four wheels, guaranteeing consistent and reliable braking. With an integrated parking brake in the transmission and a standard automatic excavation brake, the MX20G combines safety with ease of use, making it ideal for a wide range of applications.

OPERATORS CAB

The Hydrema MX20G's cab is a blend of spaciousness and ergonomic design that prioritises operator comfort. Equipped with an advanced air conditioning system with multiple air nozzles and an air suspension seat, it ensures comfort in a variety of working environments. The cab has a 10" touchscreen display and user-friendly controller in the armrest for easy operation. Features include a sliding window in the door, a split windscreen with an opening option, and a roof window for improved visibility. Comfort is complemented by adjustable steering wheel and armrests, while large mirrors and a reversing camera ensure optimal visibility. The MX20G also offers practical storage space, making it a convenient workplace.

SOUND LEVEL

The MX20G offers an impressively low noise level during operation. Inside the cab, the sound level is reduced to a comfortable 68 dB(A), and outside, the noise is kept at a moderate 102 dB(A). This low sound level contributes to a more pleasant working atmosphere for both the operator and the surroundings, making the MX20G an ideal machine for noise-sensitive work areas.

Dimensions

	Millimetre
Width across:
Blade	2550
Support, lowered	3870
Tire 10.00-20	2530
Tire 600/40-R22.5	2520
Tire 650/45-R22.5	2570
Tire 710/40-R22,5	2730
Track width with standard tires	1942
Wheelbase	2600
Distance, pivot center to rear axle	1200
Distance, pivot center to front axle	1400
Clearance height, cab	3120
Transport height	4000
Length, road transport	6320
Overhang, front (with 2.5 M stick)	3330
Rear distance, pivot center - counterweight	1700
Swing radius, rear	1839
Ground clearance, stabilizer	350
Ground clearance, wheels, lower stabilizer	50
Ground clearance, blade	510
Ground clearance, wheels, lower blade	75
Overhang, blade	1175
Overhang, stabilizer	1110
Ground clearance, axles	360
Swing radius, front
with 2.0 M dipper	1720
with 2.5 M dipper	2060
with 3.0 M dipper	2410
Total length during transport, 2.5 M dipper	9120
Height of two-piece boom during shipping, 2.5 M dipper	2920
Center shift, two-piece boom	118
Outside turn radius	6700
Inside turn radius	3600

Dimensions with standard tires 10.00-20.

MACHINE WEIGHT

Chassis
A1 - Blade	-
A3 - Blade + stabilizer	20,100
2 x A1 - Front and rear blade	-
A4 - Front and rear stabilizer	-

Weight stated with 441 lb quick hitch and 882 lb bucket

WORKING AREA AND BREAKOUT FORCE

Length of dipper	MM	2.0	2.5	3.0
Strike height		10680	11180	11670
Lifting height	MM	9610	10110	10600
Digging depth	MM	5330	5830	6330
Range	MM	9220	9720	10220
Vertical digging depth	MM	4030	4490	4970
Horizontal digging depth	MM	6440	6650	6840
Lifting height	MM	7110	7610	8110
Working depth	MM	5820	6320	6820
Range	MM	8570	9070	9570
Bucket rotation angle	0	175	175	175
Breakout force, directly mounted bucket
Breakout force, bucket (ISO)	kN	138
Digging force (ISO)	kN	111	97	86
Max. recommended bucket size
Standard bucket	M3	1.0
Max. recommended bucket size with rotor tilt
Standard bucket	M3	0.8

The working area is specified with Hydrema standard bucket and 1800 mm grab height.

Downloads

DOWNLOAD BROCHURE

DOWNLOAD LEAFLET

THE DIFFERENCES BETWEEN THE MXG SERIES MODELS

MX14G

Features the lightest counterweight in the range, resulting in the smallest swing radius
Offered with 2.0 and 2.5 metre dipper
Equipped with the shortest outer boom in the series, measuring 2900 mm
Is the most compact variant in the MXG series

MX16G

Operates as the mid-size model in the range
Equipped with a more powerful drive motor compared to the MX14G
Available with dipper in 2.0, 2.5 and 3.0 metre lengths
Maintains a low swing radius with increased excavation capacity

MX17G

A combination of features from both the MX16G and MX18G
Has the same boom length as the MX16G
Equipped with the same counterweight as the MX18G
Gives it the strongest lifting force in the series

MX18G

Has the longest boom in the entire series
Offers the most significant breaking and excavation force
Less compact than other models, but with significantly more power
The largest model in the MXG series

MX20G

Shares the same features as the MX18G
Standard equipment includes a dozer blade and supports
The heaviest model in the series
An MX18G that comes standard with a dozer blade and supports

HYDREMA MX20G: A FUSION OF POWER AND VERSATILITY

Hydrema MX20G, part of the revolutionary MXG series, defines a new standard for wheeled excavators by combining impressive power with unrivalled versatility. Uniquely equipped with both supports and dozer blade as standard, the MX20G is the most stable excavator in the range, enhancing its performance especially in challenging terrain. Its design is tailored to navigate effectively in both tight urban environments and busy construction sites, making it highly manoeuvrable.

The MX20G cab exemplifies optimum comfort and tranquillity, equipped with ergonomic design and technological innovations that ensure operator comfort and focus throughout long working days. With its powerful undercarriage and powerful hydraulic system, the MX20G is anything but a simple wheeled excavator; it's an indispensable resource on any construction project, adding unrivalled efficiency and precision.

“

Great stability and good hydraulics. Definitely worth considering when buying a new machine

HYDREMA MX20G: A DYNAMIC PLAYER IN THE EARTHMOVING INDUSTRY

The MX20G stands as an icon of quality and performance in the earthmoving industry, powered by a strong engine with up to 175 hp and a maximum torque of 780 Nm, making it a preferred machine for demanding applications.

This model combines its powerful engine with excellent fuel efficiency, contributing to significant savings on operating costs. With its state-of-the-art hydraulic system delivering an impressive 407 l/min hydraulic flow, the MX20G easily handles a diverse range of hydraulic tools, increasing its versatility.

The MX20G is designed with a focus on precise control and energy recovery from the swing brake, resulting in smooth and accurate control. The cab is created to maximise operator comfort, supporting productivity through long working days.

Safety is prioritised in the MX20G with advanced cameras and a 360-degree view that provides a complete overview of the work area and significantly increases safety.

The MX20G is characterised by its versatility and ability to adapt to the specific needs of different jobsites, from construction sites to agricultural areas.

Maintenance of the MX20G is simple and user-friendly with easy access to all service points, ensuring the machine's constant readiness and high level of functionality.

Representing an ideal solution for those looking for a combination of strength, precision and durability, the MX20G is an indispensable resource in the earthmoving sector, ready to tackle and master any challenge.

Stand Out with the MX20G in Your Chosen Colours

Don’t settle for standard—customise your MX20G with any colour from our extensive palette. Whether you’re aiming to comply with safety standards or just want to make a splash, we can accommodate your needs. Reach out to our sales team today to discuss your custom colour machine.

MX Hvid Venstre 45Gr Bag RETUSH PE21 PRESS

Hydrema Telematics

MODERN DATA MANAGEMENT AND TECHNOLOGICAL ADVANCEMENTS

Hydrema's MX20G marks a milestone in the use of advanced technology in earthmoving equipment with the integration of Hydrema Telematics. This groundbreaking system elevates the MX20G to a new dimension of intelligence and efficiency in work processes, reducing downtime and maximising productivity.

Hydrema Telematics in MX20G is a step beyond traditional GPS tracking; it is a holistic platform that provides in-depth analyses of machine performance and condition. Equipped with an integrated GSM/GPS device, the MX20G continuously transmits data that provides insight into machine operating patterns and efficiency. This enables more accurate management of maintenance schedules and prediction of necessary service interventions.

The system supports fine-tuning of fuel consumption and optimises maintenance strategies, resulting in significant cost savings. The data collected is invaluable for fleet management and project planning.

Hydrema Telematics' functionalities include comprehensive machine monitoring, real-time fault diagnostics, detailed fuel analysis and maintenance planning, all contributing to keeping the MX20G operating optimally at all times.

With Hydrema Telematics, the MX20G is transformed into a key player and intelligent work partner, ready to meet the challenges of the future with higher efficiency and reliability. Hydrema MX20G with Telematics is synonymous with a new era of advanced earthmoving capabilities.

INNOVATIVE POWER AND PRECISION FROM HYDREMA

HYDRAULICS

HIGH-PERFORMANCE HYDRAULICS FOR OPTIMISED WORK PERFORMANCE

Part of Hydrema's impressive fleet of wheeled excavators, the MX20G features a state-of-the-art hydraulic system with an impressive flow rate of 407 litres per minute. This powerful system allows the MX20G to utilise a diverse range of hydraulic tools efficiently, from shovels to grapples, delivering the necessary power combined with precision for any job. With this advanced hydraulic system, the MX20G can handle a variety of tasks with unrivalled efficiency and agility.

SAFETY

IMPROVED SAFETY AND VISIBILITY WITH MX20G

By incorporating advanced safety features, the Hydrema MX20G sets new standards in operator safety. This includes the ability to add additional cameras and a comprehensive 360-degree surveillance system that significantly expands the driver's field of vision. This enhanced visibility is essential for safe manoeuvring, especially in confined spaces and high activity areas. With these safety enhancements, the MX20G is designed to offer maximum protection and a clear view in all work situations.

Cab

GREAT COMFORT IN THE CAB

The MX20G continues the tradition of premium operator comfort and advanced technology. The spacious ROPS cab is designed with the operator's wellbeing in mind and is equipped with an efficient air conditioning system to ensure comfortable working conditions in all weather conditions. The innovative controls, including a customisable 10-inch touchscreen, make it easy to control the machine with precision and ease, resulting in a comfortable working experience.

MX20G: HYDREMA'S MOST STABLE EXCAVATOR

OUTSTANDING MANOEUVRABILITY

The MX20G from Hydrema impresses with its advanced curvature system that allows 360-degree rotation of the machine's upper body in relation to its lower body. This gives the operator exceptional control and manoeuvrability on the jobsite, which is essential in dense urban areas and on busy construction sites.

FLEXIBLE CONFIGURATION

This excavator is a true master of customisation and versatility. With its modular design, the MX20G can be tailored to meet the most specific requirements. Whether it's undercarriage options, tyre types or optional equipment like the Engcon rotor tilt, the MX20G is ready to tackle a wide range of tasks and challenging work situations with ease.

HASSLE-FREE MAINTENANCE AND SERVICE

With easy access to service points, maintenance is simple and the MX20G can even be equipped with a centralised lubrication system that automatically delivers the necessary lubricants. For an even more efficient maintenance process, you can take advantage of Hydrema Telematics, which allows you to control and monitor your machine with ease. This ensures that the MX20G is always in optimal condition and ready to deliver top performance on the jobsite.

POWERFUL ENGINE FOR VARIED APPLICATIONS

The MX20G is equipped with a dynamic Cummins engine that delivers an impressive 175 horsepower and 780 Nm of torque. This engine is designed to handle even the most challenging tasks with utmost efficiency. The perfect combination of strong performance and fuel economy makes the MX20G engine ideal for demanding working conditions, delivering reliable power and helping to minimise operating costs.

Equipment and Options

MX20G: Optimize for Peak Performance

Customize your MX20G to suit the most demanding tasks with options like wide axle dozer blades, advanced hydraulic systems, and various undercarriage configurations. Enhance your comfort and control with a ventilated seat, comprehensive cab amenities, and cutting-edge visibility solutions.
